ELP 200FPS Global Shutter USB3.0 Camera Module for Computer Wide Angle 100degree Webcam Mini UVC USB3.0/2.0 PC Camera High Speed Lightburn Cameras 1200P/120fps HD/200fps AR0234 Webcamera for Laptop
Product details
| Management number | 239451506 | Release Date | 2026/07/14 | List Price | US$37.20 | Model Number | 239451506 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
A global shutter camera can captures an image by exposing the entire sensor at once, rather than scanning the sensor line-by-line as in a rolling shutter camera. This means that all pixels in the image are exposed simultaneously, resulting in an image that is free of distortion caused by motion during exposure.It can avoid smearing when capturing high-speed motion. Product Model: ELP-U3GS0234C-H100 Product Name: 1200P Global Shutter 120FPS USB Zoom Camera Main Specifications Sensor: Aptina AR0234 (1/2.6”) Global Shutter Max Resolution: 1920 (H) *1200 (V) Sensor Size: 1/2.6 inch (4:3) Pixel Size: 3.0μm Compression Format: MJPEG / YUV2 (YUYV) Resolution & Frame rate: USB3.0 1920x1200 MJPEG 120fps/YUY2 80fps 1920x1080 MJPEG 120fps/YUY2 80fps 1600x1200 MJPEG 120fps/YUY2 80fps 1280x960 MJPEG 120fps/YUY2 120fps 1280x720 MJPEG 200fps/YUY2 200fps 640x480 MJPEG 200fps/YUY2 200fps 512x512 MJPEG 120fps/YUY2 120fps Resolution & Frame rate: USB2.0 1920x1200 MJPEG 120fps/ YUY2 5fps 1920x1080 MJPEG 120fps/ YUY2 5fps 1600x1200 MJPEG 120fps/ YUY2 5fps 1280x960 MJPEG 120fps/ YUY2 5fps 1280x720 MJPEG 200fps/ YUY2 10fps 640x480 MJPEG 200fps/ YUY2 30fps 512x512 MJPEG 120fps/ YUY2 10fps Surface Mount Technology: SMT Interface & Connector: USB 3.0 Type C Port (USB 3.0 20-Pin Connector optional) Focus: Fixed Central Definition: 600LW/PH (Center) S/N Ratio: 37dB Dynamic Range: 70dB Sensitivity: 1.4V/lux-sec@550nm Min Illumination: 0.3lux Shutter: Global Shutter Interface: USB 3.0 Interface AEC/AWB/AGC: Support Adjustable Parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Compensation, Exposure Lens Parameters: 180degree wide angle fisheye lens LED board power connector: Support 2P-2.0mm socket Power Supply: USB Type-C Power Supply Operating Voltage: DC 5V Working Current: 165mA- 210mA Dimension: 38mm x 38mmx 48.4mm Storage Temperature: -20°C to 80°C Working Temperature: -10°C to 70°C USB Cable: 1.2M Operating System Request Win10/Win11 etc. Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC
- Global Shutter: Shoot high-speed moving objects in crisp sharp images. Avoid the rolling artifacts to get a much more accurate complete picture than the rolling shutter cameras.
- FHD Resolution: 2MP 1920Hx1200V; Frame Rates: MJPEG 200fps@1280x720, YUY2 200fps@1280x720, MJPEG 120fps@1920x1200/1080P, YUY2 80fps@1920x1200/1080P, fast frame for for high-speed moving objects shooting.
- Wide Angle 100degree no distortion lens, HFOV about 98degree, mini usb camera board can be installed in most hidden and narrow position, can be used in machine visions for personal or industrial.
- USB3.0 high speed USB camera for high speed system, USB3.0/2.0 compatible, high performance ISP.
- Adopt high quality 1/2.6” Aptina AR0234 high quality sensor for sharp clear image.
- USB3.0 Type C connector, equipped with 1.2m Type C USB 3.0 cable, Support OTG optional.
- Camera with UVC for Windows,Linux,Mac,Raspberry Pi,etc.
- Plug&Play: UVC compliant, just connect the camera to PC computer, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed.
- Mini size, light weight, small outline and thin profile for embedded machine vision.
- Applications: wide angle fisheye lens usb camera module with global shutter high frame rates allow it to perform better in any application that needs gesture and eye tracking, iris and physiognomy recognition, depth and motion detection.
| ASIN | B0H3Q77QDG |
|---|---|
| Zoom | Optical |
| Brand | ELP |
| Color | 100degree No Distortion Lens |
| Features | 100degree wide angle no distortion lens, 1080P usb camera module for computer, laptop, pc, raspberry pi, Jetson Nano, global shutter, high speed USB3.0, fast frame 1080p@120fps, HD@200fps, mini size, light weight |
| Lens Type | Wide Angle |
| Focus Type | Fixed Focus |
| Model Name | ELP 200FPS Global Shutter USB3.0 Camera Module for Computer Wide Angle Webcam Board for Computer Mini UVC USB3.0/2.0 PC Camera High Speed Lightburn Cameras 1200P 120fps AR0234 Webcamera for Laptop |
| File Format | M-JPEG/yuy2 |
| Form Factor | Compact |
| Item Weight | 0.32 Kilograms |
| Screen Size | 16 Inches |
| Sensor Type | CMOS |
| Manufacturer | Shenzhen Ailipu Teconology Co.ltd |
| Model Number | ELP Global Shutter USB3.0 Camera Module |
| BuiltIn Media | 1* 1.2meters USB3.0 cable, 1* Global shutter USB camera, User Manual |
| Viewing Angle | 98 Degrees |
| Camcorder Type | Video Camera |
| Shooting Modes | Global shutter |
| Antenna Location | Dashcam, Home surveillance system, Object recognition and tracking, altimeter, baby camera, close-up camera, home video surveillance system, lightburn camera for laser engraver, monitoring 3D printer, robot and machine vision, video conference |
| Maximum Aperture | 3.24 Millimeters |
| Minimum Aperture | 3.24 Millimeters |
| Video Resolution | 1080p |
| Flash Memory Type | Micro SD |
| Photo Sensor Size | 1/2.6-inch |
| Compatible Devices | Laptop, PC, desktop computer, Personal Computer, Smartphone, Tablet |
| Image Aspect Ratio | 16:9 |
| Image Capture Speed | 200 fps |
| Image stabilization | Optical |
| Maximum Focal Length | 3.24 Millimeters |
| Minimum Focal Length | 3.24 Millimeters |
| Video Capture Format | MP4 |
| Warranty Description | 30days free return and replacements, 90 days free repair, lifetime guarranty |
| Exposure Control Type | AEC support, AWB support, Automatic |
| Are Batteries Included | No |
| Supported Image Format | MJPEG, YUY2 |
| Water Resistance Level | Not Water Resistant |
| White Balance Settings | Auto |
| Connectivity Technology | USB |
| Has Image Stabilization | Yes |
| Upper Temperature Rating | 70 Degrees Fahrenheit |
| Item Dimensions D x W x H | 1.49"D x 1.49"W x 1.5"H |
| Display Resolution Maximum | FHD Pixels |
| Effective Still Resolution | 2 MP |
| Effective Video Resolution | 1200 Pixels |
